PLY-SERIES(PLY-M18EA2)
PLY-SERIES
PLY-M18EA2
Ceiling-cassette , 18,000 BTU ,  Inverter Series ,R32 refrigerant , EGAT5 (3 Star )

Download Catalog

Download
2D CAD
print
MODEL
PLY-SM18EA2
Cooling capacity (BTU/h)
18,084
SEER (Btu/h/W)
17.49
EGAT level 5
LABEL NO.5
Cooling : Capacity Rated (kW)
5.3 (2.8-5.3)
Heating : Capacity Rated (kW)
Power Supply
1ph, 220V, 50Hz
Microprocessor Control
Automatic Temperature Control
Timer Switch
Remote Control Switch
Wireless/Wired
Indoor Fan Speeds
4 Speed+ 1AUTO
Blow Fan Indoor
Blow Fan Outdoor
Dimensions Indoor (H x W x D)
258 x 840 x 840 (mm.)
Dimensions Outdoor (H x W x D)
550 x 800 x 285 (mm.)
Weight Indoor
19
Weight Outdoor
31
Piping Size : Liquid (mm.in)
6.35 (1/4)
Piping Size : Gas (mm.in)
12.70 (1/2)
Piping Size : Max.Length / Max.Height (m)
20/12
Refrigerant
R32
Warranty
1 Years IN/OUT door heat exchanger , 5 Years Compressor , 1 Year General Part.
